BS EN 10255:2004 S195T Fluid Pipe, BS 1387, OD 10.2-165.1mm
Key Specifications / Features
Model No.: Hits: 4
BS EN 10255:2004 S195T Pipe Manufacturer: Fluid Pipe, BS EN 10255:2004 Grade S195T, BS 1387, OD 10.2-165.1mm, Length 4-12 Meters, Plain, Threaded End.
Request a quoteTags:
Detail Information
Name: Fluid pipe, as per EN 10255 (BS 1387).
OD: 10.2mm-165.1mm.
W.T.: medium and heavy.
Length: 4-12m with three types of standard, random and exact.
Standard/material:
EN 10255:2004 S195T.
Fish of pipe end:
1. Plain end.
2. Threaded ends.
3. Tube with socket.
4. Closed ends to prevent ingress of foreign matter.
Coating: Hot dip galvanized.
Usage:
Can be used for the conveyance of fluids as well as for other applications.
OD: 10.2mm-165.1mm.
W.T.: medium and heavy.
Length: 4-12m with three types of standard, random and exact.
Standard/material:
EN 10255:2004 S195T.
Fish of pipe end:
1. Plain end.
2. Threaded ends.
3. Tube with socket.
4. Closed ends to prevent ingress of foreign matter.
Coating: Hot dip galvanized.
Usage:
Can be used for the conveyance of fluids as well as for other applications.
| Steel Grade | Chemical composition % |
Mechanical Properties | ||||||
| Steel Name | Steel Number | C max |
Mn max |
P max |
S max |
Upper Yield strength ReH min. (MPa) |
Tensile strength Rm (MPa) |
Elongation A min. % |
| S 195T | 1.0026 | 0.20 | 1.40 | 0.035 | 0.030 | 195 | 320 to 520 | 20 |
